This is the Dualsky 2308C 980kv brushless motor. It is suitable for small models weighing between 400 - 600g.

Specification

• RPM/V (KV): 980
• Turns: 17
• Weight (g): 47
• Dimensions: 28.8x24.9mm
• Diameter of Shaft (mm): 3.175
• No of Cells: 3S or 4S LiPo
• Slots, Poles: 12N14P
• Idle Current (Io) @ 10V: 0.4
• Max Efficiency Current (A): 10
• Max Torque [N*M]: 0.199
• Max Burst Current (15S) [A]: 17
• Max Power (W) [15S]: 204
• Mounting Holes Pitch: 16/16mm
• Recommended ESC: XC-22-LITE or XC2512BA
• Propeller: 3S: 9x6E, 10x7E/ 4S: 7x5E, 8x6E
• Class: 400-600g, 300E class
• Input Connectors: GC3.5
• Ri(mOhm): 189
